Specifications
|
Flag: |
Slovenia |
|
Yard no.: |
PI-261 |
|
Type: |
Classic Lugger |
|
Design: |
Typical Adriatic Logger |
|
Year: |
1951 |
|
Builder: |
Shipyard Spužvar, Šibenik, CRO |
|
Year of rebuilding: |
2000-2008 |
|
Place of rebuilding: |
Shipyard Seča, Portorož, SLO |
Hull
|
Length Over All (l.o.a.): |
18.80 m |
|
Length Over Deck (l.o.d): |
15.40 m |
|
Length Waterline (l.c.w.l.): |
12.40 m |
|
Beam Max.: |
4.30 m |
|
Draft: |
1.75 m |
|
Displacement: |
32 t |
|
Hull Speed: |
10 kn |
|
Cruising Speed: |
8 kn |
|
Range Under power: |
± 1.000 nm@ 8 kn |
Sails
Sails are made of classic heavy Dacron canvas by a recognized sails manufacturer SR (Rado Sails) in Slovenia.
Sail Area
|
Total Upwind: |
115 m2 |
|
Total Downwind: |
150 m2 |
Masts, spars and booms
Masts are made of wood from carefully selected mountain pine trees, which have been well dried and glued, while the booms are made of top quality larch wood, naturally dried for several years. Spars are made from choice maple.
|
Air Draft: |
Main mast is 16.90 m above waterline |
Accommodations
|
Guests: |
6 in 3 cabins |
|
Crew: |
2 in 1 cabin |
Construction
|
Hull: |
Oak |
|
Deck: |
Iroco |
|
|
|
|
Propulsion System: |
PERKINS C130, 12V, 130 hp @ 2.600 rpm |
|
|
|
|
Bow Thrusters: |
Vetus Bow125, 7,5 kW |
Tank Capacities
|
Fuel: |
approx. 1.000 litres |
|
Fresh Water: |
approx. 1.000 litres |
Anchoring System
|
Anchor System: |
Lofrans, Falkon 1500, 24V |
|
Winches: |
Lewmar Classic |
|
Chain: |
100 m, thickness 12 mm |
|
Anchor 1: |
Fob 85 kg |
|
Anchor 2: |
Admiral 100 kg |
